MacDon M155 2022 - Return to Cut; Configuring Return to Cut Feature

215676 206 Revision A
4.4.7 Return to Cut
The return to cut (RTC) feature provides preset cutting height and tilt angle settings for the header. This feature can be
turned OFF or ON with a switch on the cab display module (CDM).
If desired, the CDM can be programmed so that only the cutting height feature is active.
The AUTO RAISE HEIGHT feature allows you to raise the header to a preselected height while in RETURN TO CUT mode.
Refer to Configuring Auto Raise Height Feature, page 208 for instructions.
Refer to the following for the RTC programming and operating procedures:
• Configuring Return to Cut Feature, page 206
• Using Return to Cut Feature, page 207
Configuring Return to Cut Feature
The return to cut (RTC) feature provides preset cutting height and tilt angle settings for the header. This feature can be
configured on the operator’s console.
1006148
A
B
C
D
E
F
Figure 4.92: Operator Console
DANGER
Ensure that all bystanders have cleared the area.
1. Start the windrower.
2. Engage the header.
3. Set RETURN TO CUT switch (A) to the OFF position. The indicator light will be dark.
4. Adjust the header to the desired cutting height using HEADER UP switch (B) and/or HEADER DOWN switch (C) on the
ground speed lever (GSL). The cab display module (CDM) will display the header height setting at location (D), which
will be a value ranging between 00.0 and 10.0.
OPERATION
