3.3 Operator’s Seat Adjustments
The operator’s seat can be adjusted in several ways so that the Operator remains comfortable while operating the
machine.
3.3.1 Adjusting Fore-Aft Position
Changing the fore-aft setting moves the operator’s chair closer to or father away from the front of the windrower.
1000573
A
Figure 3.4: Fore-Aft Position
1. Pull lever (A) up to release the fore-aft position lock.
2. Move the seat forward or rearward, as desired.
3. Release lever (A).
3.3.2 Adjusting Seat Suspension and Height
The height of the operator’s seat can be adjusted electrically by using the switch on the armrest.
1000574
A
B
Figure 3.5: Seat Suspension and Height
To increase the seat’s height, press upper switch (A).
To decrease the seat’s height, press upper switch (B).
