4.2.3 Header Functions
These symbols, found on the console, indicate that the button or indicator on which the symbol is found pertains to a
particular header function.
1000661
A
B
C
D
E
F
G
H
J
K
L
M
N
P
Q
R
S
T
U
V
W
X
Y
Z
AA
AB
AC
AD
AE
Figure 4.3: Header Function Symbols
A - Program B - Header Index C - Return to Cut
D - Conveyor/Auger Speed E - Float Left F - Float Right
G - Reel Speed H - Disc Speed J - Reel Down
K - Reel Forward L - Reel Up M - Reel Rearward
N - Display Select P - DWA Down Q - DWA Draper Speed
R - DWA Up S - Header Tilt Up T - Header Down
U - Header Up V - Header Tilt Down W - Increase
X - Decrease Y - Deck Shift Z - Float
AA - Header Engage AB - Header Disengage AC - Push Down Header Disengage
AD - Pull Up Header Engage AE - Header Reverse
