215676 214 Revision A
Adjusting Double Windrow Attachment Draper Speed
The double windrow attachment’s (DWA) draper speed can be changed by using the rotary switch on the operator’s
console. This switch should have been installed when the DWA was installed on the windrower.
Figure 4.104: DWA Draper Speed Rotary Switch on
Operator’s Console
The DWA’s draper speed can be controlled using rotary
switch (A) on the operator’s console.
OPERATION
