Removing Drive Wheel
Once the drive wheel has been raised, the wheel nuts can be removed and the wheel can be removed from the windrower.
CAUTION
Use a suitable lifting device capable of supporting a minimum of 907 kg (2000 lb.) to lift the wheel assembly away from
the windrower.
1008818
A
B
Figure 5.207: Drive Wheel
1. Raise windrower drive wheel (A) off of the ground. For
instructions, refer to Raising Drive Wheel, page 434.
2. Remove wheel nuts (B).
3. Use a suitable lifting device to remove drive wheel (A).
Installing Drive Wheel
The drive wheel will need to be handled with a lifting device to be safely installed on the windrower.
CAUTION
Use a suitable lifting device capable of supporting a minimum of 907 kg (2000 lb.) to lift the wheel.
1008812
A
B
C
D
Figure 5.208: Drive Wheel
1. Position drive wheel (A) against wheel drive hub (B) so that
air valve (C) faces away from the windrower, and tire
tread (D) points in the cab-forward direction.
NOTE:
For turf tires (diamond-treaded), ensure that the arrow on
the sidewall points in the cab-forward rotation.
2. Lift the wheel onto the hub using a suitable lifting device.
