215676 212 Revision A
4.4.11 Double Windrow Attachment
The double windrow attachment (DWA) allows the windrower to deposit two windrows of cut material close together into
a single large windrow. Using the DWA halves the number of passes needed to collect the crop once it has dried.
Figure 4.100: DWA Installed on Windrower
The DWA system is compatible with windrowers paired with an
A Series Auger Header, an R Series Rotary Disc Header, or with a
D65 Draper Header with the HC10 Hay Conditioner installed.
Raising the side delivery system shuts off the draper and allows
the crop to be deposited between the windrower wheels as it
would be without the DWA installed.
Refer to the MacDon M Series Windrower Double Windrow
Attachment Manual for the operating and maintenance
instructions.
Figure 4.101: Double Windrowing Diagram
When the DWA is active, cut crop will be deposited onto the
side delivery system draper and delivered to the side of the
windrower, as shown. To feed into the same windrow, the
second cutting pass must be made in the opposite direction of
the first.
OPERATION
