7.3 Header Operation
Several kits are available which can augment the capabilities of the header attached to the windrower, or which allow the
windrower to be used with different types of headers.
7.3.1 Draper Header Case Drain Kit
The Draper Header Case Drain kit must be installed on the windrower in order to attach a MacDon D50, D60, or D65
Draper Header equipped with an upper cross auger (UCA) without double-draper drive to the windrower. The case drain kit
(MD #B5842) is NOT required for double-draper drive headers equipped with kits MD #B5606 and MD #B6154.
MD #B5842
7.3.2 Draper Header Reel Drive and Lift Plumbing
This kit must be installed on the windrower in order for it to be able to pair with a draper header. The kit includes the
draper header reel drive and lift plumbing (less valve) and the reel fore-aft hydraulic components.
NOTE:
If the last digit of the windrower code is B, this bundle is already installed.
MD #B5577
Instruction MD #169537 is included in the bundle.
7.3.3 Header Drive Reverser
This kit allows the conditioner, knife, auger, and reel on an auger header to operate in reverse. When the windrower is
paired with a draper header, this kit allows the conditioner and knife to operate in reverse.
MD #B4656
46, 47, 48, 49
Instruction MD #169213 is included with the bundle.
7.3.4 Hydraulic Center-Link
Allows remote adjustment of the header angle using a hydraulic cylinder between the header and the windrower.
• MD #B4650 (hydraulic center-link)
• Instruction MD #169236 is included in the bundle
• MD #B5269 (auxiliary valve)
• Instruction MD #169271 is included in the bundle
7.3.5 Light Header Flotation
This kit is recommended for headers which do not require a high degree of spring tension for the header float.
MD #B4664
Instruction MD #169033 is included in the bundle.
OPTIONS AND ATTACHMENTS
46. If installed on a windrower equipped with a D Series Draper Header, only the knife circuit will reverse.
47. If installed on a windrower equipped with an A Series Auger Header, the knife, reel, auger, and conditioner will
reverse. Grass seed auger headers are not equipped with conditioners.
48. If installed on a windrower equipped with a D Series Draper Header and HC10 Hay Conditioner, knife and conditioner
will reverse.
49. R Series Disc Headers cannot use the reversing feature.
