215676 73 Revision A
Engine-Forward, Engine Running
These are the messages which can appear in the cab display module (CDM) when the windrower is in engine-forward
mode and the engine is running.
Display
Description
ROAD GEAR (upper line)
Indicates that the windrower’s transmission is in the HIGH range
#####.# ENGINE HRS (upper or lower line)
Displays the total engine operating time
#####.# UNIT HRS (upper or lower line)
Displays the total windrower operating time
#####.# HEADER HRS (upper or lower line)
Displays the total header operating time
###### TOTAL ACRES (upper or lower line)
###### TOTAL HECT (if metric)
Displays the total area cut by the machine
##.# HEADER HEIGHT (upper or lower line)
Displays the distance setting (00.0–10.0) between the cutterbar and
the ground
##.# HEADER ANGLE (upper or lower line)
Displays the angle setting (00.0–10.0) of the header relative to the
ground
### °C or F HYD OIL TEMP
Displays the temperature of the windrower’s hydraulic oil
##.# VOLTS (upper or lower line) Displays the engine electrical system’s operating voltage
##.# SWATH COMPR HT
Displays the height setting of the swath compressor (00.0–10.0); fully
raised is 0
SCROLL (lower line)
Causes the performance messages to display one after the other for
two to three seconds at a time; press SELECT to cancel scroll mode
Cab-Forward, Engine Running, Header Disengaged
These are the messages which can appear in the cab display module (CDM) when the windrower is in cab-forward mod,
the engine is running, and the header is disengaged.
Display (Lower or Upper Line) Description
#####.# ENGINE HRS
Displays the total engine operating time
#####.# UNIT HRS
Displays the windrower’s total operating time
#####.# HEADER HRS
Displays the header’s total operating time
###.# SUB ACRES
###.# SUB HECTARES (if metric)
Displays the total area cut since the last reset was performed. To reset this
value: set the CDM to display SUB ACRES on the lower line, then hold down
the PROGRAM switch for five to seven seconds until the display resets
###### TOTAL ACRES
###### TOTAL HECT (if metric)
Displays the total area cut by the machine
##.# HEADER HEIGHT
Displays the distance setting (00.0–10.0) between the cutterbar and the
ground
##.# HEADER ANGLE
Displays the angle setting (00.0–10.0) of the header relative to the ground.
##.# L FLOAT R ##.#
Displays the float setting (0.0–10.0)
### °C or F HYD OIL TEMP
Displays the temperature of the hydraulic oil
##.# VOLTS
Displays the engine electrical system’s operating voltage
##.# SWATH COMPR HT
Displays the height of the swath compressor (00.0– 10.0); fully raised is 0
SCROLL (lower line)
Causes the performance messages to display one after the other for two to
three seconds at a time; press SELECT to cancel scroll mode
OPERATOR’S STATION
