MacDon M155 2022 - Safety Sign Locations

215676 xxiii Revision A
Safety Sign Locations
1011018
A
C
D
E
B
F
G
H
J
K
L
M
N
P
Q
S
T
B
U
R
Figure 40: Safety Sign Locations – Left Cab-Forward Side
A - Hazard Sign (MD #135378) B - Cab Door and Rim (MD #166454) C - Oil Reservoir under Hood (MD #166466)
D - Exhaust Cover (MD #166450) E - Close to Radiator Cap (MD #166461) F - Fan Shroud (Top) (MD #166450)
G - Fan Shroud (Middle) (MD #166451) H - Fan Shroud (Bottom) (MD #166452) J - Frame Opening (MD #166233)
K - Platform (Left of Step) (MD #166425) L - Platform (Right of Step) (MD #166441) M - Frame at Multifunction Manifold (MD #166466)
N - Lift Linkage (MD #306179/306181) P - Inner Post (MD #166457) Q - Inner Post (MD #166234)
R - Inner Post (MD #166463) S - Neutral Interlock (MD #166425) T - Frame (MD #166425)
U - Trainer’s Seat (MD #167502)
