MacDon M155 2022 - Page 213

215676 193 Revision A
1029827
A
B
Figure 4.68: Safety Prop
3. To engage the safety props on the lift cylinders:
a. Pull lever (A) and rotate it toward the header to lower
safety prop (B) onto the cylinder.
b. Repeat the previous step for the opposite lift cylinder.
DANGER
To avoid bodily injury or death from unexpected startup of the machine, always stop the engine and remove the key
from the ignition before leaving the operator’s seat for any reason.
1029697
A
Figure 4.69: Safety Prop
4. To disengage the safety props on the lift cylinders:
a. Turn lever (A) away from the header to raise the safety
prop until the lever locks into the vertical position.
b. Repeat the previous step for the opposite cylinder.
WARNING
Check to be sure all bystanders have cleared the area.
5. Start the engine.
6. Lower the header fully.
7. Shut down the engine, and remove the key from the
ignition.
OPERATION
