MacDon M155 2022 - Page 350

215676 330 Revision A
1000619
A
Figure 5.21: Operator Console
1. Place ground speed lever (GSL) (A) in the N-DETENT
position.
2. Shut down the engine, and remove the key from the
ignition.
1000833
A
B
Figure 5.22: Steering Rods
3. Check steering rod bolts (A) for looseness and ball joints (B)
for any perceptible movement.
1000834
A
B
Figure 5.23: Steering Rods – Pump End
MAINTENANCE AND SERVICING
