Figure 5.43: Batteries
4. Remove positive (red) cables (A) from the battery posts
first, then remove negative (black) cables (B) from the
remaining battery posts.
Figure 5.44: Access Hole Location for Barring Tool
5. At the left cab-forward side of the engine, clean the area
around the plastic cap on access hole (A). Remove the cap.
IMPORTANT:
Ensure that nothing falls into the gearbox oil reservoir.
6. Insert barring tool (B) into the flywheel housing until it
engages the ring gear.
7. Attach a 1/2 in. square-drive ratchet or breaker bar to the
barring tool and turn it.
8. Remove barring tool (B), and then clean the oil from around
access hole (A).
9. Clean the plastic cap. Apply silicone sealant to the cap and
reinstall it in access hole (A).
