215676 364 Revision A
Figure 5.82: Fuel Shut-off Valve
3. Close fuel shut-off valve (A) located on the bottom of the
fuel tank.
Figure 5.83: Fuel System
4. Place a 20 liter (5 US gallon) drain pan under fuel supply
hose (A) at the primary filter.
5. Loosen clamp (B) and pull fuel supply hose (A) off of its
fitting.
Figure 5.84: Fuel Shut-off Valve
6. Route the hose to the drain pan, and then open valve (A) to
drain the fuel tank.
MAINTENANCE AND SERVICING
