215676 398 Revision A
Figure 5.140: Road Light Switch (except Russia)
Figure 5.141: Road Light Switch (Russia Only)
3. Turn on ROAD lights (A) and set HIGH-LOW switch (B) to
LOW BEAM.
Figure 5.142: Headlights
4. To align the headlights, you will need to tighten or loosen
any or all of adjusting screws (A). Ensure that the beam
remains centered when making adjustments.
NOTE:
The adjustments made apply only to the headlights when
they are in low-beam mode.
MAINTENANCE AND SERVICING
