215676 401 Revision A
1. Turn the lights OFF.
2. Shut down the engine, and remove the key from the ignition.
Figure 5.147: Forward Floodlights
3. Holding onto handholds (A) on the cab’s front corners,
stand on the header’s anti-slip strips.
4. Remove two screws (B). Remove light bezel (C).
5. Remove the floodlight body from its receptacle.
Figure 5.148: Floodlight Assembly
6. Pinch wire retainer (A) and lift it away from the hooks.
7. Remove bulb (B) from the floodlight body. Remove the wire
from connector (C).
MAINTENANCE AND SERVICING
