215676 36 Revision A
Figure 2.3: Rear Cab-Forward View
A - Caster Wheel B - Walking Beam C - Taillights - Cab-Forward (Option)
D - Engine Compartment Hood E - Windshield Wiper F - Field Lights
G - Horn H - Turn Signal / Hazard Lights J - Mirror
K - Door L - Drive Wheel M - Maintenance Platform
N - Engine Air Precleaner (Export) P - Headlights
PRODUCT OVERVIEW
