215676 64 Revision A
The autosteer engagement switch harness has two connectors:
Figure 3.46: Autosteer Harness SW1
GSL SW1 (A) is located in the cab, beneath the floor mat at the
engine-end seat position switch.
Figure 3.47: Autosteer Harness SW2
GSL SW2 (A) is located beneath the cab, between the fuel tank
and the evaporator box.
OPERATOR’S STATION
