215676 69 Revision A
Figure 3.56: Header Switches
A - Deck Shift / Float Preset Switch B - Float Preset 1
C - Float Preset 2 D - Float Preset 3
Draper header with fixed decks / auger header / rotary
disc header
When a fixed-deck draper header, auger header, or rotary disc
header is attached to the windrower, this switch is used to
select one of the preprogrammed header float settings. Refer to
Float Options, page 196 to learn how to configure these
presets.
OPERATOR’S STATION
