T–112
CRUISE CONTROL SYSTEM
End Of Sie
ACTUATOR CABLE REMOVAL
A6E812866311W01
1. Remove the plug hole plate.
2. Remove the cover from the cruise actuator. (See T–110 CRUISE ACTUATOR REMOVAL/INSTALLATION.)
3. Remove the installation nut and pull the cruise actuator toward you.
4. Move the throttle, and remove the end fitting of
the actuator cable from the throttle.
5. Squeeze the hooks of the grommet, and remove
the actuator cable.
J
Cruise control
switch position
Cruise control
switch
Inspect for
resistance
Cruise control
main switch
held at on
0 ohm
• Inspect cruise control
switch
(See T–116 CRUISE
CONTROL SWITCH
INSPECTION)
• Inspect related
harness
SET/COAST
switch held at
on
Approx. 680
ohms
RESUME/
ACCEL switch
held at on
Approx.
2200 ohms
CANCEL
switch held at
on
Approx. 120
ohms
K Brake switch on/off Brake switch 2
Ignition switch
at ON position
Depress brake
pedal
Below 1.0
• Inspect brake switch 2
(See P–8 BRAKE
SWITCH
INSPECTION)
• Inspect related
harness
Other B+
LIG1
METER IG 15 A
fuse
Ignition switch at ON position B+ • Inspect METER IG 15
A fuse
• Inspect related
harness
Ignition switch at LOCK
position or ACC position
Below 1.0
Terminal Signal Connected to Test condition
Voltage (V)
/Continuity
Action
A6E8128W007
To Next Page
