CONTROL SYSTEM
U–33
U
AIRFLOW MODE ACTUATOR REMOVAL/INSTALLATION
A6E854061070W01
1. Disconnect the negative battery cable.
2. Remove the glove compartment.
3. Remove the car navigation unit. (See T–98 CAR-NAVIGATION UNIT REMOVAL/INSTALLATION.)
4. Remove in the order indicated in the table.
5. Install in the reverse order of removal.
End Of Sie
1 Airflow mode actuator connector
2 Airflow mode actuator
A6E8540W007
