TECHNICAL DATA
TD–5
TD
CLUTCH
A6E931001024W01
End Of Sie
MANUAL TRANSAXLE
A6E931001024W02
End Of Sie
AUTOMATIC TRANSAXLE
A6E931001024W03
Item Specification
Clutch pedal
Height (with carpet) mm {in}
L.H.D.: 216—222 {8.50—8.74}
R.H.D.: 229—235 {9.02—9.25}
Free play
Pedal free play mm {in} 1.0—3.0 {0.04—0.11}
Push rod free play mm {in}
0.1—0.5 {0.004—0.02}
(Reference value)
Disengagement
point
Disengagement stroke mm {in}
20 {0.79}
(Reference value)
Pedal stroke mm {in}
130.7 {5.15}
(Reference value)
Clutch cover
Diaphragm
spring fingers
Depth mm {in} 0.6 {0.024}
Misalignment mm {in} 0.6 {0.024}
Maximum clearance of flatness of the
pressure plate
mm {in} 0.5 {0.020}
Clutch disc
Minimum thickness mm {in} 0.3 {0.012}
Run out limit mm {in} 0.7 {0.028}
Flywheel Run out limit mm {in} 0.1 {0.004}
Item Specification
Manual transaxle type G35M-R
Transaxle oil
Grade API service GL-4 or GL-5
Viscosity
All-season SAE 75W-90
Above 10 °C {50 °F} SAE 80W-90
Capacity (L {US qt, lmp qt}) 2.87 {3.03, 2.53}
Item Specification
Transaxle type FN4A-EL
ATF Type ATF M-V
Line pressure
(kPa {kgf/cm
2
, psi})
D, S, L range
Idle 330—470 {3.4—4.8, 48—68}
Stall 1,160—1,320 {11.8—12.5, 168—191}
R position
Idle 490—710 {5.0—7.2, 71—102}
Stall 1,600—1,820 {16.3—18.6, 232—264}
Engine stall speed (rpm)
D, S, L range 2,000—2,600
R position 2,000—2,600
Time lag (s)
N → D 0.4—0.7
N → R 0.4—0.7
Transaxle range
(TR) switch
(ohm)
P position 4,085—4,515
R position 1,425—1,575
N position 713—788
D range 371—410
S range 190—210
L range 87—96
Transaxle Fluid temperature (TFT)
sensor
(kilohm)
ATF temperature: –20 °C {–4 °F} 236—324
ATF temperature: 0 °C {32 °F} 84.3—110
ATF temperature: 20 °C {68 °F} 33.5—42.0
ATF temperature: 40 °C {104 °F} 14.7—17.9
ATF temperature: 60 °C {140 °F} 7.08—8.17
ATF temperature: 80 °C {176 °F} 3.61—4.15
ATF temperature: 100 °C {212 °F} 1.96—2.24
ATF temperature: 120 °C {248 °F} 1.13—1.28
ATF temperature: 130 °C {266 °F} 0.87—0.98
