TD–6
TECHNICAL DATA
End Of Sie
FRONT AND REAR AXLE
A6E931001018W01
End Of Sie
STEERING SYSTEM
A6E931001034W01
* : When reservoir tank is at maximum volume
End Of Sie
Input/turbine speed sensor
(ohm)
ATF temperature: –40—160 °C {–40—
320 °F}
250—600
Vehicle speedometer sensor (VSS)
(V)
4.5—5.5
Solenoid valve (ohm)
ATF
temperature:
–40—150 °C
{–40—302 °F}
Shift solenoid A 1.0—4.2
Shift solenoid B 1.0—4.2
Shift solenoid C 1.0—4.2
Shift solenoid D 10.9—26.2
Shift solenoid E 10.9—26.2
Pressure control 2.4—7.3
Item Specification
Item
Specification
ATX MTX
FRONT AXLE
Maximum wheel bearing play (mm {in}) 0.05 {0.002}
REAR AXLE
Maximum wheel bearing play (mm {in}) 0.05 {0.002}
DRIVE SHAFT
Shaft length (Air in
boot at atmospheric
pressure)
(mm {in})
Left side 674.5—684.5 {26.56—26.94}
677.7—687.7 {26.67—27.07} (L8, LF),
676.6—686.6 {26.64—27.03} (L3)
Right side 631.2—641.2 {24.86—25.24} 628.6—638.6 {24.75—25.14}
Item Specification
ENGINE SPEED SENSING POWER STEERING
Steering wheel
Play (mm {in}) 0—30 {0—1.18}
Effort (N·m {kgf·cm, in·lbf}) 7.8 {80, 58} max.
Steering shaft Length (mm {in}) 211.6 {8.3}
Steering gear
Tie-rod end
Rotation torque (N·m {kgf·cm, in·lbf}) 0.4—2.7 {3.5—27.5, 3.1—23.8}
[Pull scale reading] (N {kgf, lbf}) 3.4—25.5 {0.35—2.60, 0.8—5.7}
Tie rod
Swinging torque (N·m {kgf·cm, in·lbf}) 0.1—4.0 {1—40.7, 0.9—35.3}
[Pull scale reading] (N {kgf, lbf}) 0.6—24.5 {0.06—2.49 0.2—5.5}
Steering
rack
Runout
Large diameter
portion
0.15 mm {0.006 in} max.
(mm {in}) Small diameter
portion
0.20 mm {0.008 in} max.
Power steering oil
pump
Oil pump fluid pressure
(MPa {kgf·cm
2
, psi})
10.80—11.29 {110.2—115.2, 1567—1637}
Gear housing fluid pressure
(MPa {kgf·cm
2
, psi})
10.80—11.29 {110.2—115.2, 1567—1637}
Power steering
system
Fluid
Type
ATF M-
III
or equivalent (e.g. Dexron
®
II
)
Capacity*
(Approximate
quantity)
(L {US qt, Imp qt})
0.80 {0.85, 0.70} (MTX)
0.87 {0.92, 0.77} (ATX)
