TECHNICAL DATA
TD–7
TD
BRAKING SYSTEM
A6E931001020W01
End Of Sie
Item Specification
CONVENTIONAL BRAKE SYSTEM
Brake pedal
Brake pedal height (mm {in})
R.H.D.: 172 {6.77}
L.H.D.: 187 {7.36}
Brake pedal play (mm {in}) 0—3 {0—0.1}
Pedal-to-floor clearance
(Brake pedal when
depressed at 588 N {60 kgf,
132 lbf})
(mm {in}) 68 {2.7} min.
Power brake
unit
Fluid pressure when pedal
depressed at
200 N {20 kgf, 44 lbf}
At 0 kPa {0
mmHg, 0 inHg}
588 {5.95, 84.7} min.
(kPa {kgf/cm
2
, psi})
At 66.7 kPa
{500 mmHg,
19.7 inHg}
8,787 {89.60, 1,274} min.
Dual
proportioning
valve (without
ABS)
Switching point
(kPa {kgf/cm
2
,
psi})
2,450 {25, 355} ±200 {2, 29}
Rear wheel pressure when master cylinder
pressure is 5,880 kPa {60 kgf/cm
2
, 853 psi}
3,480 {35.5, 505} ±300 {3, 44}
(kPa {kgf/cm
2
, psi})
Front disc
brake
Minimum disc pad
thickness
(mm {in}) 2.0 {0.079}
Minimum disc plate
thickness
(mm {in})
L8, LF (GCC specs.): 22 {0.87}
LF (European (L.H.D. U.K.) specs.), L3: 23 {0.91 }
Disc plate runout limit (mm {in}) 0.05 {0.002}
Rear disc
brake
Minimum disc pad
thickness
(mm {in}) 2.0 {0.079}
Minimum disc plate
thickness
(mm {in}) 8 {0.31}
Disc plate runout limit (mm {in}) 0.05 {0.002}
Brake fluid Type
European (L.H.D. U.K.) specs.: SAE J1703, FMVSS 116 DOT3
OR DOT4
GCC specs.: SAE J1703, FMVSS 116 DOT3
PARKING BRAKE SYSTEM
Parking brake
lever
Lever stroke when pulled at
98 N {10 kgf, 22 lbf} (notches)
3—6
