FRONT AXLE
M–7
M
Dust Cover Removal Note
Note
• The dust cover does not need to be removed unless it is being replaced.
1. Mark the dust cover and steering knuckle for
proper installation.
2. Remove the dust cover using a chisel.
Hub Bolt Removal Note
Note
• The hub bolts do not need to be removed unless they are being replaced.
1. Remove the hub bolts using a press.
Hub Bolt Installation Note
1. Install the new hub bolts using a press.
A6E0311W018
A6E0311W019
A6E6312W003
A6E6312W004
