M–8
FRONT AXLE
Dust Cover Installation Note
1. Mark the new dust cover in the same way as the
removed one.
2. Align the marks of the new dust cover and the
knuckle.
3. Install the new dust cover using the SSTs.
Wheel Bearing Installation Note
1. Install the new wheel bearing using the SSTs.
Wheel Hub Component Installation Note
1. Install the wheel hub component using the SSTs.
A6E0312W010
A6E0312W011
A6E0312W012
A6E0312W013
