TIMING CHAIN
B–15
B
2. Install the cylinder head cover bolts in the order
as shown.
Front Oil Seal Installation Note
1. Apply clean engine oil to the oil seal.
2. Push the oil seal slightly in by hand.
3. Compress the oil seal using the SST and a
hammer.
Bolt No. Tightening torque
1—18 8.0—11.5 N·m {81.6—117.2 kgf·cm,
70.9—101.7 in·lbf}
19—22 40—55 N·m {4.1—5.6 kgf·m, 29.7—40.5 ft·lbf}
AME2215W008
AME2215W009
AME2215W010
