N–24
ENGINE SPEED SENSING POWER STEERING
Power Steering Oil Pump Component Disassembly Note
1. Secure the power pressure oil pump using the
SST.
Caution
• Use the SST to prevent damage to the
pump when securing it in a vise.
Clip Disassembly Note
1. Lift up the clip tab using a flathead screwdriver.
2. Remove the clip pushing with a flathead
screwdriver and a hammer as shown in the figure.
Clip Assembly Note
1. Push the clip slowly to the direction shown in the
figure.
2. Confirm that the clip tab is caught correctly.
A6E0612W070
A6E0612W098
A6E0612W100
