P–56
ON-BOARD DIAGNOSTIC (ABS/TCS)
End Of Sie
DTC C1145, C1155, C1165, C1175
A6E697567650W10
Caution
• When attaching the tester lead to the ABS (ABS/TCS) HU/CM harness connector, the SST (49 G066
001) must be used. (See P–29 ABS (ABS/TCS) HU/CM INSPECTION.)
DTC
C1145
C1155
C1165
C1175
RF wheel-speed sensor
LF wheel-speed sensor
RR wheel-speed sensor
LR wheel-speed sensor
DETECTION
CONDITION
• Abnormal input is detected.
POSSIBLE
CAUSE
• Open or short to ground circuit in harness between ABS (ABS/TCS) HU/CM terminal and wheel-speed
sensor(s) terminal below
— ABS (ABS/TCS) HU/CM terminal G—RF ABS wheel-speed sensor terminal A
— ABS (ABS/TCS) HU/CM terminal D—RF ABS wheel-speed sensor terminal B
— ABS (ABS/TCS) HU/CM terminal I—LF ABS wheel-speed sensor terminal A
— ABS (ABS/TCS) HU/CM terminal E—LF ABS wheel-speed sensor terminal B
— ABS (ABS/TCS) HU/CM terminal A—RR ABS wheel-speed sensor terminal A
— ABS (ABS/TCS) HU/CM terminal B—RR ABS wheel-speed sensor terminal B
— ABS (ABS/TCS) HU/CM terminal C—LR ABS wheel-speed sensor terminal A
— ABS (ABS/TCS) HU/CM terminal F—LR ABS wheel-speed sensor terminal B
• ABS wheel-speed sensor(s) malfunction
