T–50
INTERIOR LIGHTING SYSTEM
CARGO COMPARTMENT LIGHT REMOVAL/INSTALLATION
A6E811451441W01
1. Disconnect the negative battery cable.
2. Remove in the order indicated in the table.
3. Install in the reverse order of removal.
End Of Sie
CARGO COMPARTMENT LIGHT INSPECTION
A6E811451441W02
1. Remove the cargo compartment light. (See T–50 CARGO COMPARTMENT LIGHT REMOVAL/
INSTALLATION)
2. Inspect for continuity between the cargo
compartment light terminals using an ohmmeter.
• If not as specified, replace the cargo
compartment light.
End Of Sie
CARGO COMPARTMENT LIGHT SWITCH INSPECTION
A6E811451442W01
1. Remove the liftgate lower trim. (See S–95 LIFTGATE LOWER TRIM REMOVAL/INSTALLATION)
2. Disconnect the cargo compartment light switch connector.
3. Inspect for continuity between the cargo
compartment light switch terminals using an
ohmmeter.
• If not as specified, replace the liftgate lock.
End Of Sie
1 Cargo compartment light
2 Connector
3 Lens
4 Cargo compartment light bulb
A6E8114W101
A6E8114W111
A6E8114W114
A6E8114W119
A6E8114W120
