13 SFC PROGRAM INSTRUCTIONS
13.1 SFC Control Instructions
1419
13
DMOV(P) [K8S/BL\K8S]
These instructions batch-read (in units of 32-bit binary data) the status (active or inactive) of steps in the specified block, and
store the read data in the specified device.
■Execution condition
■Description, range, data type
■Applicable devices
*1 Only S can be used.
• The RnCPU and RnENCPU with firmware version "12" or later support this instruction. (Use an engineering tool with version "1.015R" or later.)
• The RnPCPU (process) with firmware version "03" or later supports these instructions. (Use an engineering tool with version "1.020W" or later.)
Ladder ST
ENO:=DMOV(EN,s,d);
ENO:=DMOVP(EN,s,d);
FBD/LD
Instruction Execution condition
DMOV
DMOVP
Operand Description Range Data type Data type (label)
(s) Device number where the transfer source data is stored 32-bit signed binary ANY32
(d) Transfer destination device number 32-bit signed binary ANY32
EN Execution condition Bit BOOL
ENO Execution result Bit BOOL
Operand Bit Word Double word Indirect
specification
Constant Others
(BL\
S)
X, Y, M, L,
SM, F, B, S,
SB, FX, FY
J\ T, ST, C, D, W,
SD, SW, FD, R,
ZR, RD
U\G, J\,
U3E\(H)G
Z LT, LST,
LC
LZ K, H E $
(s)
*1
(d)
RnCPU
RnENCPU
RnSFCPU RnSFCPURnPCPURnPCPU
(Standard) (Safety)
(Redundant)
(Process)
