7 APPLICATION INSTRUCTIONS
7.4 Structure Creation Instructions
565
7
■Applicable devices
*1 Devices other than F can be used.
• In safety programs executed by the Safety CPU, only the following safety devices and constants can be used.
Processing details
• When the FCALL (P) instruction is executed, this instruction executes non-execution processing
*2
of the subroutine
program of the pointer (P). The FCALL(P) instruction can disable the execution of the subroutine program specified by a
pointer in the same program file or the subroutine program specified by a global pointer.
*2 Non-execution processing is the same as the processing performed by each coil instruction with the condition contact set to off.
• The operation results of individual coil instructions after the end of non-execution processing are as follows regardless of
on/off of the condition contact.
• The FCALL(P) instruction is used in combination with the CALL(P) instruction. If the FCALL(P) instruction is not used in
combination with the CALL(P) instruction, non-execution processing of the subroutine program is not performed even if the
execution command is turned off, and therefore the output status of each coil instruction is retained.
Operand Bit Word Double word Indirect
specification
Constant Others
(P)
X, Y, M, L,
SM, F, B, SB,
FX, FY
J\ T, ST, C, D, W,
SD, SW, FD, R,
ZR, RD
U\G, J\,
U3E\(H)G
Z LT, LST,
LC
LZ K,
H
E $
(P)         
(s1)(s5) 
*1
       
Operand Bit Word Constant
SA\X, SA\Y, SA\M, SA\SM, SA\B SA\T, SA\ST, SA\C, SA\D, SA\W, SA\SD K, H
(s) 
A: Main routine program
B: Subroutine program
(1) Non-execution processing is performed when the command of the
FCALL(P) instruction changes from on to off.
Device used for operation Operation result (device status)
High-speed timer, low-speed timer Set to 0
High-speed retentive timer, low-speed retentive timer, counter Maintains the current status.
Device in OUT instruction Forcibly turned off.
Device in the SET, RST, SFT(P), or basic/application instruction Maintains the current status.
PLS or pulse instruction (P) Performs the same processing as when the condition contact
is off.
FCALL (P)
END
(P)
RET
(1)
A B
