6. DIRECT CONNECTION TO CPU
6.1 Connectable Model List
6. DIRECT CONNECTION TO CPU
6.1 Connectable Model List
The following table shows the connectable models.
(Continued to next page)
*1 When in multiple CPU system configuration, use CPU function version B or later.
*2 Access via the (RS-232) in the multiple CPU system.
*3 Use a module with the upper five digits of the serial No. later than 12042.
Series Model name Clock
Communication
type
Connectable model Refer to
MELSEC-Q
(Q mode)
Q00JCPU
RS-232
RS-422
6.2.1
Q00CPU
*1
Q01CPU
*1
Q02CPU
*1
Q02HCPU
*1
Q06HCPU
*1
Q12HCPU
*1
Q25HCPU
*1
Q02PHCPU
Q06PHCPU
Q12PHCPU
Q25PHCPU
RS-232
RS-422
6.2.1
Q12PRHCPU (Main base)
Q25PRHCPU (Main base)
Q12PRHCPU
(Extension base)
- -
Q25PRHCPU
(Extension base)
Q00UJCPU
RS-232
RS-422
6.2.1
Q00UCPU
Q01UCPU
Q02UCPU
Q03UDCPU
Q04UDHCPU
Q06UDHCPU
Q10UDHCPU
Q13UDHCPU
Q20UDHCPU
Q26UDHCPU
Q03UDECPU
Q04UDEHCPU
Q06UDEHCPU
Q10UDEHCPU
Q13UDEHCPU
Q20UDEHCPU
Q26UDEHCPU
Q50UDEHCPU
Q100UDEHCPU
RS-232
*2
6.2.1
Q03UDVCPU
Q04UDVCPU
Q06UDVCPU
Q13UDVCPU
Q26UDVCPU
C Controller
module
Q12DCCPU-V
*3
Q24DHCCPU-V
Q24DHCCPU-LS
RS-232
*2
6.2.1
MELSEC-QS QS001CPU - -
