Mitsubishi GOT2000 Series Connection Manual

18. GOT MULTI-DROP CONNECTION
18.2 Connectable Model List
18 - 3
18
GOT MULTI-DROP CONNECTION
18.2 Connectable Model List
 Connecting the CPU to the Serial Multi-Drop Connection Unit (hereinafter referred to as "master
module") directly
The following table shows the connectable models.
(Continued to next page)
*1 When in multiple CPU system configuration, use CPU function version B or later.
*2 Access via the (RS-232) in the multiple CPU system.
*3 Use a module with the upper five digits of the serial No. later than 12042.
*4 Ww and Wr devices cannot be monitored.
Series Model name Clock
Communication type
Connectable model
Between CPU
and master
module
Between
master module
and GOT
MELSEC-Q
(Q mode)
*4
Q00JCPU
RS-232
RS-422
RS-485
Q00CPU
*1
Q01CPU
*1
Q02CPU
*1
Q02HCPU
*1
Q06HCPU
*1
Q12HCPU
*1
Q25HCPU
*1
Q02PHCPU
--
Q06PHCPU
Q12PHCPU
Q25PHCPU
Q12PRHCPU (Main base)
Q25PRHCPU (Main base)
Q12PRHCPU (Extension base)
--
Q25PRHCPU (Extension base)
Q00UJCPU
RS-232
RS-422
RS-485
Q00UCPU
Q01UCPU
Q02UCPU
Q03UDCPU
Q04UDHCPU
Q06UDHCPU
Q10UDHCPU
Q13UDHCPU
Q20UDHCPU
Q26UDHCPU
Q03UDECPU
RS-232 RS-485
*2
Q04UDEHCPU
Q06UDEHCPU
Q10UDEHCPU
Q13UDEHCPU
Q20UDEHCPU
Q26UDEHCPU
Q50UDEHCPU
Q100UDEHCPU
Q03UDVCPU
Q04UDVCPU
Q06UDVCPU
Q13UDVCPU
Q26UDVCPU
C Controller
module
Q12DCCPU-V
*3
RS-232 RS-485
*2
Q24DHCCPU-V
Q24DHCCPU-LS
MELSEC-QS
*4
QS001CPU - -

Mitsubishi GOT2000 Series Specifications

General

Power Supply	24VDC
Software	GT Works3
Processor	RISC CPU
Interface	Ethernet, USB, RS-232, RS-422/485
Operating Temperature	0°C to 50°C
Display Type	TFT LCD
Storage Temperature	-20°C to 60°C
Humidity	10% to 90% (non-condensing)
Shock Resistance	147 m/s² (15G), 11ms duration
Touch Panel	Analog Resistive
