17. CNC CONNECTION
17.2 System Configuration
17 - 5
17
CNC CONNECTION
17.2.3 CC-Link connection (intelligent device station)
*1 The overall extension cable length and the length between stations vary depending on the cable type to be used and the total
number of stations.
For details, refer to the following manuals.
C6/C64/C64T CONNECTION AND MAINTENANCE MANUAL BNP-B2255
C6/C64/C64T NETWORK INSTRUCTION MANUAL BNP-B2373
*2 Specify Ver.1 as the mode setting in the Communication Settings to use it.
For details of the settings, refer to the following the manual.
17.4.1 Setting communication interface (Communication settings)
*3 For the specifications and inquiries of the CC-Link dedicated cable, refer to the following.
CC-Link Partner Association's home page: http://www.cc-link.org/
Expansion
unit
GOT
Connection cable
MELDAS
C6/C64
CC-Link Ver2(ID)
Communication driver
CNC Connection cable GOT
Number of
connectable
equipment
Model name Expansion unit
Communication
type
Cable model
Max.
distance
Option device Model
MELDAS C6/C64 FUC6-HR865 CC-Link(ID)
CC-Link dedicated
cable
*3
*1
GT15-J61BT13
*2
26 GOTs
