3 - 18
3. ACCESS RANGE FOR MONITORING
3.5 Access Range for Monitoring when Connecting FXCPU
Setting method of monitor device
The following example describes the method of setting the network No. and the station numbers when setting
monitor devices .
(1) Monitoring the connected station (host station) and B and W allocated by the link parameter
Specify the host station.
(2) Monitoring devices of other stations
Network No.: 0, Station number: Refer to the following table.
Setting of the station No.
Monitoring link device B or W
For monitoring devices B and W that are allocated by the link parameter, use the host device number even when
designating devices allocated to another station.
Otherwise, the display speed will be reduced.
3.5 Access Range for Monitoring when Connecting
FXCPU
The access range that can be monitored for the direct CPU connection is only the connected CPU. (The GOT cannot
monitor other stations.)
The access range that can be monitored for the Ethernet connection is the host and others.
The access range that can be monitored for the multi-drop communication is only the CPU to which the serial multi-drop
connection unit (GT01-RS4-M) is connected directly.
Station to be accessed
Station
connected to GOT
M L1
L2
m
L3
1 2 3
M Host Other 1 Other 2 Other 3 ―― ―
L1 Other 0 Host ―――― ―
L2
m
Other 0 ― Host ― Other 1 Other 2 Other 3
L3 Other 0 ――Host ―― ―
1
――Other 0 ― Host ――
2
――Other 0 ――Host ―
3
――Other 0 ―――Host
To Next Page
