20. FA TRANSPARENT FUNCTION
20.4 System Configuration
20.4.4 MR Configurator, MR Configurator2
When connecting the GOT and the personal computer by USB
*1 Only MR Configurator2 is compatible with the Ethernet connection.
Connection type
dependant
Communication driver
GOT
Servo
amplifier
Servo
amplifier
QCPU +
Motion controller
CPU (Q series)
PC
Connection cable
Varies according to
the connection type.
SSCNET , SSCNET /H
PLC GOT Connection cable
Personal
computer
Number of
connectable
equipment
Connection type Model Interface Cable model
Max.
distance
Software
For the system configuration between
the GOT and PLC, refer to the following.
DIRECT CONNECTION TO
CPU
ETHERNET CONNECTION
*1
USB
GT09-C30USB-5P(3m)
GT09-C20USB-5P(2m)
3m
MR Configurator
MR Configurator2
1 personal
computer for 1 GOT
For the system configuration between
the GOT and PLC, refer to the following.
BUS CONNECTION
USB
GT09-C30USB-5P(3m)
GT09-C20USB-5P(2m)
3m
MR Configurator
MR Configurator2
1 personal
computer for 1 GOT
