Mitsubishi GOT2000 Series Connection Manual

15 - 8
15. SERVO AMPLIFIER CONNECTION
15.2 System Configuration
15.2.4 Connecting to the MELSERVO-JE Series
 When connecting via RS-422 communication
*1 Connect the connector of the servo amplifier to CN1.
GOT
Connection cable
Servo
amplifier
Servo
amplifier
CHARGE
MITSUBISHI
CHARGE
MITSUBISHI
Communication driver
MELSERVO-J4, J3, J2S/M, JE
Servo amplifier Connection cable GOT
Max.
distance
Number of connectable
equipment
Series name
Communi
cation
type
Connection diagram
number
Option device Model
MELSERVO-JE
*1
RS-422
RS422 connection
diagram 6)
- (Built into GOT)
30m
Up to 32 axes for 1 GOT
(multi-drop
communication)
GT15-RS4-9S

Mitsubishi GOT2000 Series Specifications

General

Power Supply	24VDC
Software	GT Works3
Processor	RISC CPU
Interface	Ethernet, USB, RS-232, RS-422/485
Operating Temperature	0°C to 50°C
Display Type	TFT LCD
Storage Temperature	-20°C to 60°C
Humidity	10% to 90% (non-condensing)
Shock Resistance	147 m/s² (15G), 11ms duration
Touch Panel	Analog Resistive
