19. MULTI-CHANNEL FUNCTION
19.3 GOT Side Settings
19 - 11
19
MULTI-CHANNEL FUNCTION
19.3.2 General flow from system selection to drawing
System selection for using the multi-channel function is explained below.
Make selection and setting for the multi-channel function by following the order shown below.
System selection
Determine the connection type and the channel No. to be used.
19.3.3
Determining the connection type and channel No. (System selection)
Interface selection
Determine the GOT side interface and communication units to
be used for the multichannel function.
19.3.4
Determining the GOT side interface (Interface selection)
Checking the unit installation position
Determine the communication unit installation position.
1.3.5
Installing a unit on another unit (Checking the unit installation position)
Make settings for Communication Settings.
19.3.5
Setting for communication settings
Confirm items to know before starting drawing.
19.3.6
Items to be checked before starting drawing

Mitsubishi GOT2000 Series Specifications

General

Power Supply	24VDC
Software	GT Works3
Processor	RISC CPU
Interface	Ethernet, USB, RS-232, RS-422/485
Operating Temperature	0°C to 50°C
Display Type	TFT LCD
Storage Temperature	-20°C to 60°C
Humidity	10% to 90% (non-condensing)
Shock Resistance	147 m/s² (15G), 11ms duration
Touch Panel	Analog Resistive
