19. MULTI-CHANNEL FUNCTION
19.5 Multi-channel Function Check Sheet
19.5 Multi-channel Function Check Sheet
This section provides the check sheet to be used for Communication Settings when the multi-channel function is used.
Sections 20.3.3 to 20.3.5 contain explanations of the items to be checked on the check sheet.
Checking items explained in these sections using the check sheet on the following page allows you to complete the
setting for the multi-channel function.
Write Check
Sheet
The following symbols are used for each purpose.
Indicates parts where items and details are to be written.
Confirm the details and write them to the check sheet.
Indicates parts where written details are to be checked.
Confirm the details and perform the Communication Settings.
Check
Enter the selections having been made in the steps above to the check sheet.
Selection of connection type
Enter the name of connection type to be used.
Section 2.8.10
Multi-channel function
check sheet
Write Check
Sheet
Shows items and
contents to be written on
the check sheet.
Also describes an
example of the check
sheet.
