18 - 22
18. GOT MULTI-DROP CONNECTION
18.6 Setting of Serial Multi-Drop Connection Unit
18.6.3 Setting switches
Set the switches according to the connection type.
POINTPOINTPOINT
Serial Multi-Drop Connection Unit
For details on the Serial Multi-Drop Connection Unit,
refer to the following manual.
Serial Multi-Drop Connection Unit User’s
Manual
Terminating resistor
selector switch
PLC communication
selection switch
