13 - 12
13. CC-Link CONNECTION (Via G4)
13.5 PLC Side Settings
13.5 PLC Side Settings
13.5.1 Connecting AJ65BT-G4-S3
This section describes the settings of the GOT and
peripheral connection module in the following case of the
system configuration.
POINTPOINTPOINT
(1) Peripheral connection module
For details of the peripheral connection module,
refer to the following manual.
Peripheral Connection Module Type AJ65BT-
G4-S3 User's Manual (detail volume)
(2) CC-Link module
For details of the CC-Link module, refer to the
following manual.
CC-Link System Master/Local Module User's
Manual QJ61BT11N
MELSEC-L CC-Link System Master/Local
Module User's Manual
(3) CC-Link function built-in CPU
For details on the CC-Link function built-in CPU,
refer to the following manual.
MELSEC-L CC-Link System Master/Local
Module User's Manual
System configuration
*1 The Start I/O No. of the CC-Link module is set to "0"
Switch setting of peripheral connection
module
Set the station number setting switch, data link
transmission speed setting switch, and operation
setting DIP switch.
(1) Station number setting switch
: Necessary : As necessary : Not necessary
(2) Data link transmission speed setting switch
: Necessary : As necessary : Not necessary
Model Reference
Peripheral connection
module
AJ65BT-G4-S3 13.5.1
AJ65BT-R2N 13.5.2
<CC-Link module>
*1
Station type
Station No.
Mode
All connect count
Transmission speed
<AJ65BT-G4-S3>
Station type
Station No.
Number of stations occupied
Transmission speed
<GOT>Setting example
Transmission speed: 9600bps
: Master station
: Station No. 0
: Remote net (Ver.1 mode)
: 1
: Intelligent device station
: Station No. 1
: Exclusive station 1
: 156kbps
: 156kbps
Setting example
Setting example
13.5.3 Switch setting of CC-Link module (Q series)
13.5.4 [Network parameter] of GX Developer
Switch setting of peripheral connection module
13.5.6 [Controller Setting] of GT Designer3
Station number setting
switch
Description Set value
Setting
necessity at
GOT
connection
AJ65BT-G4-S3
station number
setting
1 to 64
Data link transmission
speed setting switch
Description Set value
Setting
necessity at
GOT
connection
Data link
transmission
speed setting
0: 156kbps
1: 625kbps
2: 2.5Mbps
3: 5Mbps
4: 10Mbps
(2) (1)
(3)
B RATE STATION NO.
x
10
x
1
SW
18234567
ON
RESET
PW
RUN
L RUN
SD
RD
L ERR.
MITSUBISHI
A
J65BT-G4-S3
RS-422
5
0
6
9
2
7
8
1
3
4
5
0
6
2
1
3
4
0
2
1
3
4
SW1 MODE
QnA
A
non-used
Q
SW6
OFF
OFF
ON
ON
OFF
OFF
ON
ON
STATION NO.
×10 ×1
5
0
6
9
2
7
8
1
3
4
5
0
6
2
1
3
4
B RATE
0
2
1
3
4
