1. PREPARATORY PROCEDURES FOR MONITORING
1.6 Checking for Normal Monitoring
1 - 25
1
PREPARATORY PROCEDURES FOR MONITORING
1.6 Checking for Normal Monitoring
1.6.1 Check on the GOT
Check for errors occurring on the GOT
Presetting the system alarm to project data allows you to identify errors occurred on the GOT, PLC CPU, servo
amplifier and communications.
For details on the operation method of the GOT Utility screen, refer to the following manual.
GOT2000 Series User's Manual (Utility)
HINTHINTHINT
Alarm popup display
With the alarm popup display function, alarms are displayed as a popup display regardless of whether an alarm
display object is placed on the screen or not (regardless of the display screen).
Since comments can be flown from right to left, even a long comment can be displayed all.
For details of the alarm popup display, refer to the following manual.
GT Designer3 (GOT2000) Help
Error code Communication Channel No.
Error message Time of occurrence
(Displayed only for errors)
