Mitsubishi GOT2000 Series Connection Manual

3
3 - 1
3
ACCESS RANGE FOR MONITORING
3. ACCESS RANGE FOR MONITORING
3.1 Access Range for Monitoring Stations on Network Systems
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 - 2
3.2 Access Range for Monitoring when Using Ethernet Connection
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 - 13
3.3 CC-Link System Access Range for Monitoring . . . . . . . . . .3 - 14
3.4 Data Link System (MELSECNET/B, (II)) Access Range for
Monitoring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 - 17
3.5 Access Range for Monitoring when Connecting FXCPU . . .3 - 18
3.6 Connection to Remote I/O Station in MELSECNET/H Network
System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 - 19
3.7 Connection to the Head Module of CC-Link IE Field Network
System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 - 22

Mitsubishi GOT2000 Series Specifications

General

Power Supply	24VDC
Software	GT Works3
Processor	RISC CPU
Interface	Ethernet, USB, RS-232, RS-422/485
Operating Temperature	0°C to 50°C
Display Type	TFT LCD
Storage Temperature	-20°C to 60°C
Humidity	10% to 90% (non-condensing)
Shock Resistance	147 m/s² (15G), 11ms duration
Touch Panel	Analog Resistive
