1. PREPARATORY PROCEDURES FOR MONITORING
1.3 Option Devices for the Respective Connection
1 - 15
1
PREPARATORY PROCEDURES FOR MONITORING
1.3 Option Devices for the Respective Connection
The following shows the option devices to connect in the respective connection type.
For the specifications, usage and connecting procedure on option devices, refer to the respective device manual.
1.3.1 Communication module
Product name Model Specifications
Bus connection unit
GT15-QBUS
For QCPU (Q mode), motion controller CPU (Q series)
Bus connection (1ch) unit standard model
GT15-QBUS2
For QCPU (Q mode), motion controller CPU (Q series)
Bus connection (2ch) unit standard model
GT15-ABUS
For A/QnACPU, motion controller CPU (A series)
Bus connection (1ch) unit standard model
GT15-ABUS2
For A/QnACPU, motion controller CPU (A series)
Bus connection (2ch) unit standard model
GT15-75QBUSL
For QCPU (Q mode), motion controller CPU (Q series)
Bus connection (1ch) unit slim model
GT15-75QBUS2L
For QCPU (Q mode), motion controller CPU (Q series)
Bus connection (2ch) unit slim model
GT15-75ABUSL
For A/QnACPU, motion controller CPU (A series)
Bus connection (1ch) unit slim model
GT15-75ABUS2L
For A/QnACPU, motion controller CPU (A series)
Bus connection (1ch) unit slim model
Serial communication unit
GT15-RS2-9P RS-232 serial communication unit (D-sub 9-pin (male))
GT15-RS4-9S RS-422/485 serial communication unit (D-sub 9-pin (female))
GT15-RS4-TE RS-422/485 serial communication unit (terminal block)
MELSECNET/H communication unit
GT15-J71LP23-25 Optical loop unit
GT15-J71BR13 Coaxial bus unit
MELSECNET/10 communication unit
GT15-J71LP23-25
Optical loop unit
(MELSECNET/H communication unit used in the MNET/10 mode)
GT15-J71BR13
Coaxial bus unit
(MELSECNET/H communication unit used in the MNET/10 mode)
CC-Link IE Controller
Network communication unit
GT15-J71GP23-SX Optical loop unit
CC-Link IE Field
Network communication unit
GT15-J71GF13-T2 CC-Link IE Field Network (1000BASE-T) unit
CC-Link communication unit GT15-J61BT13 Intelligent device station unit CC-LINK Ver. 2 compatible
Ethernet communication unit Built into GOT Ethernet (100Base-TX)
Wireless LAN communication unit GT25-WLAN
For the connection to personal computer,
IEEE802.11b/g/n compatible, built-in antenna,
station (wireless LAN adapter), for Japanese domestic use
