9. MELSECNET/H CONNECTION (PLC TO PLC NETWORK), MELSECNET/10 CONNECTION (PLC TO
PLC NETWORK)
9 - 11
MELSECNET/H CONNECTION (PLC TO PLC NETWORK),
MELSECNET/10 CONNECTION (PLC TO PLC NETWORK)
9
9.2.2 Connecting to the coaxial bus system
*1 Use a PLC CPU of function version B or a later version.
*2 For the system configuration of the MELSECNET/H network module, refer to the following manual.
Q corresponding MELSECNET/H Network System Reference Manual (PLC to PLC network)
For QnA/Q4AR MELSECNET/10 Network System Reference Manual
For AnU MELSECNET/10 Network System Reference Manual (PLC to PLC network)
Use a MELSECNET/H network module of function version B or a later version.
MELSECNET/H
network module
GOT
Connection cable
QCPU
MELSECNET/H
Communication driver
PLC Connection cable GOT
Number of
connectable
equipment
Model name
MELSECNET/H
network module
*2
Communication
type
Cable model
Max.
distance
Option device Model
MELSEC-Q
QJ71BR11 MELSECNET/H
Optical fiber cable
*3
*4
GT15-J71BR13
31 GOTs
QJ71BR11 MELSECNET/10
Optical fiber cable
*3
*4
GT15-J71BR13
*5
C Controller
module
QJ71BR11 MELSECNET/H
Optical fiber cable
*3
*4
GT15-J71BR13
QJ71BR11 MELSECNET/10
Optical fiber cable
*3
*4
GT15-J71BR13
*5
MELSEC-QS
QJ71BR11 MELSECNET/H
Optical fiber cable
*3
*4
GT15-J71BR13
QJ71BR11 MELSECNET/10
Optical fiber cable
*3
*4
GT15-J71BR13
*5
MELSEC-QnA
AJ71QBR11
A1SJ71QBR11
MELSECNET/10
Optical fiber cable
*3
*4
GT15-J71BR13
*5
MELSEC-A
AJ71BR11
A1SJ71BR11
MELSECNET/10
Optical fiber cable
*3
*4
GT15-J71BR13
*5
