9. MELSECNET/H CONNECTION (PLC TO PLC NETWORK), MELSECNET/10 CONNECTION (PLC TO
PLC NETWORK)
*3 For the coaxial cable, refer to the following manual.
Q corresponding MELSECNET/H Network System Reference Manual (PLC to PLC network)
For QnA/Q4AR MELSECNET/10 Network System Reference Manual
For AnU MELSECNET/10 Network System Reference Manual (PLC to PLC network)
For the coaxial cable connector connection method, refer to the following.
1.4.2 Coaxial cableconnector connection method
*4 The overall extension cable length and the length between stations vary depending on the cable type to be used and the total
number of stations.
For details, refer to the following manual.
Q corresponding MELSECNET/H Network System Reference Manual (PLC to PLC network)
For QnA/Q4AR MELSECNET/10 Network System Reference Manual
For AnU MELSECNET/10 Network System Reference Manual (PLC to PLC network)
*5 Set the MELSECNET/10 mode in the communication settings. For the setting, refer to the following.
9.3.1 Setting communication interface (Communication settings)
