Mitsubishi GOT2000 Series Connection Manual

7 - 10
7. COMPUTER LINK CONNECTION
7.2 System Configuration
7.2.4 Connecting to QnACPU (QnACPU type)
*1 For details on the system configuration on the serial communication module side, refer to the following manual.
Serial Communications Module User’s Manual (Modem Function Additional Version)
*2 For details of the GOT multi-drop connection, refer to the following.
18. GOT MULTI-DROP CONNECTION
Communication driver
AJ71QC24,MELDAS C6*
(
When connecting to a serial communication module )
Serial communication
module
/Computer link module
QnACPU
(QnACPU type)
GOT
Connection cable
AJ71C24/UC24
Communication driver
(When connecting to a computer link module)
PLC Connection cable GOT
Number of
connectable
equipment
Model name
Serial
communication
module
*1
Commun
ication
type
Cable model
Max.
distance
Option device Model
MELSEC-QnA
(QnACPU)
AJ71QC24
AJ71QC24N
AJ71QC24-R2
AJ71QC24N-R2
RS-232
GT09-C30R2-25P(3m)
or
RS232 connection
diagram 2)
15m
- (Built into GOT)
1 GOT for 1 serial
communication
module
GT15-RS2-9P
GT01-RS4-M
*2
-
AJ71QC24-R4
AJ71QC24N-R4
RS-422
GT01-C30R4-25P(3m)
GT01-C100R4-25P(10m)
GT01-C200R4-25P(20m)
GT01-C300R4-25P(30m)
30m
- (Built into GOT)
GT15-RS4-9S
GT01-RS4-M
*2
-
AJ71QC24
AJ71QC24N
AJ71QC24-R4
AJ71QC24N-R4
RS-422
GT09-C30R4-6C(3m)
GT09-C100R4-6C(10m)
GT09-C200R4-6C(20m)
GT09-C300R4-6C(30m)
or
RS422 connection
diagram 1)
1200m
- (Built into GOT)
GT15-RS4-9S
GT01-RS4-M
*2
-
