19. MULTI-CHANNEL FUNCTION
19.3 GOT Side Settings
19.3.3 Determining the connection type and channel No. (System selection)
Determining the connection type
For GOT27, the combinations of the bus or network connection, the Ethernet connection, and the serial connection
are available as shown in the following table.
(Continued to next page)
Connection type Reference
Bus/network connection
Bus connection 5. BUS CONNECTION
MELSECNET/H connection (PLC to PLC network) 9. MELSECNET/H CONNECTION (PLC TO PLC NETWORK)
MELSECNET/10 connection (PLC to PLC network) 10. MELSECNET/10 CONNECTION (PLC TO PLC NETWORK)
CC-Link IE Controller Network connection 11. CC-Link IE CONTROLLER NETWORK CONNECTION
CC-Link IE Field Network connection 12. CC-Link IE FIELD NETWORK CONNECTION
CC-Link connection (intelligent device station) 13. CC-Link CONNECTION (INTELLIGENT DEVICE STATION)
CNC connection (MELSECNET/10 connection
(PLC to PLC network))
18.2.2 MELSECNET/10 connection (PLC to PLC network)
CNC connection (CC-Link connection (intelligent
device station))
18.2.3 CC-Link connection (intelligent device station)
Ethernet connection
Ethernet connection 8. ETHERNET CONNECTION
Robot controller connection 17. ROBOT CONTROLLER CONNECTION
CNC connection (Ethernet connection) 18.2.4 Ethernet connection
Third party PLC connection (Ethernet connection)
Non-Mitsubishi Products 1
• 3. CONNECTION TO OMRON PLC 3.3 Ethernet Connection
Non-Mitsubishi Products 2
• 6. CONNECTION TO YASKAWA PLC 6.3 Ethernet Connection
• 7. CONNECTION TO YOKOGAWA PLC 7.3 Ethernet Connection
• 10. CONNECTION TO ALLEN-BRADLEY PLC 10.3 Ethernet Connection
• 14. CONNECTION TO SIEMENS PLC 14.3 Ethernet Connection
Microcomputer connection (Ethernet)
Microcomputer, MODBUS Products, Peripherals
• 3. MICROCOMPUTER CONNECTION (ETHERNET)
MODBUS
®
/TCP connection
Microcomputer, MODBUS Products, Peripherals
• 5. MODBUS(R)/TCP CONNECTION
Serial connection
Direct CPU connection 6. DIRECT CONNECTION TO CPU
Computer link connection 7. COMPUTER LINK CONNECTION
CC-Link connection (via G4) 14. CC-Link CONNECTION (Via G4)
Inverter connection 15. INVERTER CONNECTION
Servo amplifier connection 16. SERVO AMPLIFIER CONNECTION
CNC connection (serial connection) 18.2.1 Direct connection to CPU
GOT Multi- Drop Connection 19. GOT MULTI-DROP CONNECTION
Third party PLC connection (serial connection)
Non-Mitsubishi Products 1
• 4. CONNECTION TO OMRON PLC 4.2 Serial Connection
• 6. CONNECTION TO KEYENCE PLC
• 7. CONNECTION TO KOYO EI PLC
• 8. CONNECTION TO JTEKT PLC
• 9. CONNECTION TO SHARP PLC
• 12. CONNECTION TO TOSHIBA PLC
• 13. CONNECTION TO TOSHIBA MACHINE PLC
• 15. CONNECTION TO PANASONIC EW PLC
Non-Mitsubishi Products 2
• 2. CONNECTION TO HITACHI IES PLC
• 3. CONNECTION TO HITACHI PLC
• 4. CONNECTION TO FUJI FA PLC
• 6. CONNECTION TO YASKAWA PLC 6.2 Serial Connection
• 7. CONNECTION TO YOKOGAWA PLC 7.2 Serial Connection
• 10. CONNECTION TO ALLEN-BRADLEY PLC 10.2 Serial Connection
• 11. CONNECTION TO GE FANUC PLC
• 16. CONNECTION TO MURATEC CONTROLLER
To Next Page
