19. MULTI-CHANNEL FUNCTION
19.5 Multi-channel Function Check Sheet
19 - 29
19
MULTI-CHANNEL FUNCTION
Check sheet No.1 (selection of connection type and interface)
(1) Channel No. of PLC, motion controller CPU, temperature controller, inverter, servo amplifier, CNC, robot
controller (No.1 to No.4)
(2) Channel No. of barcode reader, RFID controller, personal computer (CH No. 5 to 8)
CH
No.
Selection of connection type
( 19.3.3)
Selection of interface (communication unit)
( 19.3.4)
1
Connection name
2
Connection name
3
Connection name
4
Connection name
CH
No.
Selection of connection type
( 19.3.3)
Selection of interface (communication unit)
( 19.3.4)
5
Connection name
6
Connection name
7
Connection name
8
Connection name
