Mitsubishi GOT2000 Series Connection Manual

8. BUS CONNECTION
8.2 System Configuration
8 - 9
8
BUS CONNECTION
*4 When connecting 3 or more GOTs, the overall cable length is restricted.
8.4.12 When connecting multiple GOTs
*5 The connection of multiple GOTs
When connecting to multiple GOTs withGT27, GT 16, GT15 and GT11 mixed, use GT11 as a terminal.
*6 The bus connection unit
GT15-75QBUSL, GT15-QBUS: Used for a terminal GOT. (Not available for an intermediary GOT)
GT15-75QBUS2L, GT15-QBUS2: Used for an intermediary GOT. (Can be used for a terminal GOT)
*7 When using the following functions, use GT15-QBUS(2). GT15-75QBUS(2)L cannot be used.
Remote personal computer operation (Serial), video display function, multimedia function, external I/O device, RGB display
function, sound output function
Communication driver
Bus(Q)
Connection cable 2)
GOT (intermediary)
*4*5
Connection cable 3)
GOT (terminal)
*4*5
Max. distance
Option device
*6*7
Model
Option device
*6*7
Model
GT15-QC06B(0.6m)
GT15-QC12B(1.2m)
GT15-QC30B(3m)
GT15-QC50B(5m)
GT15-QC100B(10m)
GT15-QC150BS(15m)
GT15-QC200BS(20m)
GT15-QC250BS(25m)
GT15-QC300BS(30m)
GT15-QC350BS(35m)
GT15-75QBUS2L,
GT15-QBUS2
GT15-QC06B(0.6m)
GT15-QC12B(1.2m)
GT15-QC30B(3m)
GT15-QC50B(5m)
GT15-QC100B(10m)
GT15-QC150BS(15m)
GT15-QC200BS(20m)
GT15-QC250BS(25m)
GT15-QC300BS(30m)
GT15-QC350BS(35m)
GT15-75QBUSL,
GT15-75QBUS2L,
GT15-QBUS,
GT15-QBUS2
Between main base and GOT
(1st): 13.2m
Between main base and GOT
(terminal): 37m
GT15-75QBUS2L,
GT15-QBUS2
GT15-75QBUSL,
GT15-75QBUS2L,
GT15-QBUS,
GT15-QBUS2
Between main base and GOT
(1st): 13.2m (Including the
extension cable length)
Between main base and GOT
(terminal): 37m (Including the
extension cable length)
GT15-75QBUS2L,
GT15-QBUS2
GT15-75QBUSL,
GT15-75QBUS2L,
GT15-QBUS,
GT15-QBUS2
Between main base and GOT
(terminal): 37m
GT15-75QBUS2L,
GT15-QBUS2
GT15-75QBUSL,
GT15-75QBUS2L,
GT15-QBUS,
GT15-QBUS2
Between main base and GOT
(terminal):
37m (Including the extension
cable length)
